Casement Windows
Introduction
Our flush faced timber Casement Window provides outstanding performance with a range of styles. Our Conservation Casement Windows can be tailored to suit a multitude of styles from small pane Georgian, leaded Arts and Craft to minimalistic Contemporary.
As part of the Conservation range our timber Casement Windows offer a choice of frame profiles and glazing bars, along with a variety of double glass unit depths and specification to ensure that your aesthetic, thermal and acoustic requirements are achieved.
Gallery
Finish
RAL Classic Range
Typically in RAL 9003 Signal White but our customers may choose from the RAL Classic swatch.
Colour matching service
On request we are able to offer a colour matching service.
Dual colour finish
We are able to offer a ‘dual finish’ where different colours are desired internally and externally or a ‘mixed finish’ where frames are specified to be contrasting to sashes.
Stain finish
Our products are also available finished with a pigmented stain in a variety of shades to suit your requirements.
Glazing
24mm DGU
Standard Specification
24 mm Double glass unit comprising 4 mm Tough / 16 mm Argon / 4 mm Tough Planitherm Total+
14mm DGU
Standard Specification
14 mm Double glass unit comprising 4 mm Tough / 6 mm Krypton / 4 mm Tough Planitherm One
4mm Single
Standard Specification
4mm Single Toughened Pane
Glass Specification Options
There are many alternative specifications available such as Acoustics, Laminates, Obscure and Solar options, please contact us to discuss your requirements.
Ironmongery
Bulb end casement handle
Polished Chrome
Bulb end casement handle
Satin Chrome
Bulb End Casement Handle
Polished Brass
Bulb End Casement Handle
Antique Brass
Bulb end casement handle
Oil Rubbed Bronze
Bulb end casement handle
Satin Nickel
Bulb end handle
Bulb end handle
Black
Bulb end handle
Pewter
Monkey Tail Handle
Monkey Tail Handle
Black
Monkey Tail Handle
Pewter
Technical Specifications
| Thermal | As Standard | Best |
| U-Value | 1.3 | 1.3 |
| g-Value | 50% | As Required |
| LT | 79% | As Required |
| Acoustic | ||
| Rw | 36dB Rw | 44dB Rw |
| Weather | ||
| Standard | BS6375 Part 1 | |
| Air | Class 4 (EN 12207:2000) | |
| Wind | Class C5 (EN 12210:2000) | |
| Water | Class 7A (EN 12208:2000) | |
| Operation & Strength | ||
| Classification | Pass (BS6375 Part 2) | |
| Sustainability | ||
| FSC Chain of Custody | Yes | |
| Security | ||
| PAS 24 / Part Q | Pass (as option) |
CAD Drawings
Sign in to view CAD profiles
